Scott Aerator: Solar Sub-Surface Aeration System | Standard | Up to 2.5 Acres

The Scott Aerator Solar Sub-Surface Aeration System Standard delivers diffused bottom aeration without batteries, AC wiring or the ongoing cost of grid power, and keeps working in cloudy conditions. It is sized for ponds up to 2.5 acres.

A high-efficiency, brushless, rocking-piston compressor, managed by a digital motor controller, offers over three times the system life of brushed permanent-magnet motors. The pole-mount enclosure has an integrated sound reduction system (less than 65 dB at 6 ft), a washable and reusable intake filter, liquid-filled pressure gauges, stainless steel locking hardware and electronic over-current protection. Each unit is factory tested and built from American-made components.

Applications include ponds and lakes, de-icing, golf courses, fish farms, marinas, parks, livestock watering, storm water, habitat management and weed and algae control. A vertical 3" (3-1/2" OD) galvanized pole about 10 ft long is required for mounting and is not included.

Need more air? See the Solar Sub-Surface Aeration System XL for ponds up to 5 acres.

Specifications

• Model: 45000
• Pond size: up to 2.5 acres
• Solar: one 300 W, 60-cell high-efficiency module (39" x 65") with adjustable top-of-pole racking
• Compressor: 1 brushless rocking-piston
• Airflow: 2.5 SCFM at 25 psi, rated 30+ ft deep
• Airline: one 3/8" x 300 ft
• Diffusers: 2 self-weighted
• Valves: 2 full-flow brass ball valves, brass automatic pressure relief valve
• Noise: under 65 dB at 6 ft
• Ventilation: 78 CFM automatic active ventilation
• Warranty: 2 years on all components
